RHMS80-175.PTS Multistage Pressure Pump

Model Number: RHMS80-175.PTS
Max flow: Tooltip 180 L/min
Head/Draw: Tooltip 80m
Pump rating: Tooltip 66m, 88 L/min
Inlet/Outlet size: 32mm
No. taps/outlets: 8 - 14
Horse power: Tooltip 2.95HP, 2.2kw
Amp draw: 12.4 amps
Voltage: 240 volt
Packaging Size (cm): 48.5 x 28 x 64.2cm
Packaging Weight (kg): 18.85kg
Liquid to be pumped: Clean Water
$ 2758.00
INCL GST
Add to Cart
Rating: Not Rated Yet

The Reefe RHMS80-175 multistage pressure pump comes with a pressure tank, switch, gauge and tee and is designed for reliable performance at high demands in domestic, farm and commercial applications. Made in Europe, these lightweight, heavy duty, multistage pressure pumps are made for ease of installation. A quiet running and efficient multistage pump for trouble free pressure pump operation.

The RHMS series of multistage pressure pumps come with a wide range of size options together with the option of purchasing the pump only, pump with a controller or pump with pressure tank, switch and gauge.

Reefe Multistage Pressure Pump Applications

  • Amenities blocks, hotels, restaurants
  • Whole house supply
  • Apartment blocks
  • Irrigation supply
  • Stock watering systems

Reefe RHMS series multistage pressure pump specifications

Reefe Multistage Pressure Pump Features

  • Assembled with European automatic pressure controller with run dry protection
  • Quiet operation for minimal disturbance in application
  • Lower power consumption for greater efficiency
  • Maximum 35°C
  • Fitted with digital pressure switch for easy installation and adjustment
  • 3 year manufacturers warranty

Reefe Multistage Pressure Pump Construction

  • Heavy Duty 304 stainless steel housing
  • In-built thermal overload protection on motor
  • Brass barrell union
  • Noryl/fibreglass diffusers
  • Stainless steel impeller
  • Supplied with 18 litre pressure tank, EPS1 pressure switch and pressure gauge
  • 5 way brass tee with combo check valve
  • Oil filled pressure gauge
  • Ingress prostection - IP44
  • Insulation Class F

9 multistage pressure pumps in the RHMS series with pressure tank, switch and gauge
