RM5000-4 w RPS57E pump and RM1600-2 valve

Model Number: RM5000-4 w RPS57E + RM1600-2
Max flow: Tooltip 90 L/min
Head/Draw: Tooltip 57m
Horse power: Tooltip 0.75kw. 6 amp.
Voltage: 240 volt
Cable length: 10 metres
Packaging Size (cm): 12.7 x 61cm
Liquid to be pumped: Clean water
$ 1488.00
Add to Cart
Rating: Not Rated Yet

The RM5000-4 submersible rain to mains pressure pump system features a submersible multistage pressure pump with integral controller and changeover valve set and has been specifically designed for a fast and easy installation. The rain to main pressure pump system is 100% European made, guaranteeing exceptional quality and performance in rainwater supply applications. This submersible pressure pump system is suitable for underground tanks and best suited for supply to toilet, laundry and garden taps /outlets. Two year warranty. NSW Basix compliant.

Available with 2 rain to main submersible pressure pump size options. RPS57E (this listing) or RPS34E.

Submersible Rain To Mains Pump System Application

  • Bathrooms and laundry
  • Whole house - refer to the data table below for sizing
  • Small commericial/ industrial *
  • Garden irrigation *
  • Toilet blocks (up to 6 fixtures) *
  • Construction/ mine site offices*

*Check specifications required

Reefe RM5000 4 submersible rain to mains pressure pump system

Submersible Rain To Mains Pump System Construction

  • Stainless Steel AISI 304 Pump body, motor shaft, handle, cover, screen
  • Polymer Impellers, diffusers
  • Alumina Graphite, lubricated mechanical seal
  • Valveset made from DZR Brass

Submersible Rain To Mains Pump System Features


  • Automatic start and stop on demand
  • Mains flow - 50L/ Min
  • Integrated pressure controller with 220kPa/ 2.2 bar cut-in
  • Supplied with 10m H07RN-F cable
  • Integrated run-dry protected
  • Internal blockage detection systems, which shuts down the pump if debris obstructs the internal check valve
  • Compact design, water cooled motor
  • Thermal overload protection

RM system

  • Rain to mains valve with minimal pressure reduction on mains supply
  • Integrated check valve, 100% Hydraulic
  • Corrosion resistant
  • Certified to AS/NZS4020 for use with potable water
