Reefe RWC03 Wastewater Treatment Controller

Model Number: RWC03
$ 614.00
INCL GST
Add to Cart

The Reefe RWC03 is a generic controller suitable for use in a wide range of domestic waste treatment systems. If the system uses a permanently powered pump and air blower then the RWC03 provides a reliable, cost effective solution for moitoring the system for faults such as a blower failure or high level.

  • If the treatment plant has a power outlet in the motor box then no electrician is required for installation
  • Permanently powered pump and blower outputs
  • Air pressure and high level sensing via analogue sensores instead of pressure switches. Unlike pressure switches which can fail over time these sensors will provide long term reliable operation
  • Compatible with either the 2 wire remote alarm plate or a strobe and siren for alarm indication
  • Compact, robust mechanical design
  • Internal, strong surge protection
  • Meets the control and alarm requirements of AS/NZS 1546.3 2017 for Aerated Wastewater Treatment Systems
  • Compatible with all relevant Australian electrical product safety standards (RCM)
  • Optional WiFi for remote monitoring using Wastewater Cloud
  • 2 year warranty

Specifications

  • Code: 27042
  • Model: RWC03
  • Power: 240v
  • Controller Power Draw: 5W
  • Maximum load: 10A
  • Operating Temperature: 0°C to 50°C
  • Weight: 0.85kg
  • Size: 240mm(L) x 140mm(W) x 85(H)
